TECHNICAL PARAMETERS
|
| Simple operation |
| Keyboard calibration and configuration |
| Weighing up to 1:15,000 divisions |
| Excitation voltage : DC 5V; Up to 4，350 Ω load cells can be used |
| Manual or automatic memory accumulation facility |
| High Resolution (×10) Display |
| Selectable digital filtering |
| Selectable automatic power off |
| 6-bit Display : 0.8 inches LED |
| Selectable display resolution : 1 / 2 / 5 / 0.1 / 0.2 / 0.5 / 0.01 / 0.02 / 0.05 / 0.001 / 0.002 / 0.005 / 10 / 20 / 50 / 100 / 200 / 500 / 0.10 / 0.20 / 0.50 / 0.010 / 0.020 / 0.050 |
| RS–232C The interface , optional RS–485 interface 1200 2400 4800 9600 Baud rate continuous ASCII data output |
| External Power supply : 230V(115V) AC. Internal rechargeable 6V DC Battery |
| Operating temperature : 0℃ to 40℃.Storage temperature: -25℃ to 55℃ |
| Relative humidity : ≤ 85% non–condensing |
| Dimensions : 256mm wide × 165mm high ×130mm deep |
